| MIG 350 | MIG 400 | MIG 500 N398 | |
|---|---|---|---|
| Input power source | 3~AC410V+-20%50/60Hz | ||
| Rated Input Current(A) | 22 | 26.5 | 40.6 |
| Rated Input Power Capacity (KVA) | 15.6 | 18.8 | 24.2 |
| Power Factor(cos #) | 0.9 | 0.9 | 0.92 |
| No-load Voltage(V) | 60 | 62 | 80 |
| Rated Output(A/V) | 350/31.5 | 400/36 | 500/39 |
| Welding Voltage(V) | 15.5-38 | 15.5-40 | 15.5-50 |
| Welding Current(A) | 30-350 | 30-400 | 30-500 |
| Wire Speed(m/min) | 1.5-18 | 1.5-18 | 1.5-22 |
| Output Characteristics | MMA :CC MIG/MAG : CV | ||
| Rated duty cycle(%)@40°C | 60 | 100 | 100 |
| Efficiency(%) | 85 | 85 | 91 |
| Protection Class | IP21S | IP21S | IP23 |
| Insulation Class | F | F | F |
| Dimensions(mm) | 648 x 293 x 526 | 648 x 293 x 526 | 785 x 330 x 666 |
| Weight(Kg) | 40 | 40 | 59 |
